The series is a door control actuator, which is a double output structure brake. The brake is a whole structure, and the installation is simple and convenient.   Main Technical Data   Size Rated Transmitting Torque N.M Rated Voltage D.C.V Coil Consumption power(20℃) Max Engagement Revolution r/min Allowed Max Revolution r/min  SK-10-SL 100 24   18 50 2000

               The series of products for the power loss of the structure of the door control actuator, power off brake, long time brake state energy saving and environmental protection, with a manual release device, in the absence of electricity, can be released through the release of the handle brake. The brake is an integral whole structure, and the installation is simple and convenient. Main Technical Data Size Rated Transmitting Torque N.M Rated Voltage D.C.V Coil Consumption power(20℃) Max Engagement Revolution r/min Allowed Max Revolution r/min SK-10-2 100 24   23 50 2000

　         This series is a jaw type brake, this brake is a dual-output structure brake, one end is pulley output, and the other end is encoder installation shaft output. This brake is an integral structure and is easy to install. Main Technical Data Size Rated Transmitting Torque N.M Rated Voltage D.C.V Coil Consumption power(20℃) Max Engagement Revolution r/min Allowed Max Revolution r/min DZY0-16D 160 24   24 50 2000
